🛠 KTool Update — Rig Analyzer (Quick Guide)The Rig Analyzer turns a simple boat photo into a clear rig-tuning snapshot. Use lines, perpendiculars, and circles to mark mast bend, sail shape, and alignment — giving you a visual, data-driven view of your setup.
How it works:- Draw lines on key elements: mast, boom, leech, spreaders.
- Add perpendiculars to check rake, prebend, or outhaul geometry.
- Use circles to highlight bend radius or camber zones.
The sidebar automatically shows relative lengths and angles — letting you quantify changes even without exact scale.
When you're done, export everything to PDF for sharing with your coach or keeping a tuning log.
